Brand : | Lenotel |
Effective Megapixels | 4K/8MP;5.0MP(2592*1944);4.0MP(2592*1520);3.0MP(2048*1536) ;1080P(1920*1080) |
Image Sensor | 1/2.8, Sony 335 , 5.0MP IP |
Lowest Illumination | Color 0.01 Lux |
Resolution | 2592(H) * 1944(V) |
S/N Ratio | >=50db |
Video processing | PAL/NTSC available, support Auto White Balance, 3D noise reduction, Support wide dynamic,Support anti-face overexposure, defogging function, Compression:H.264 / H.265/ H.265+ available,Achieve ultra-low storage, Stream / Fps adjustable |
Mainstream: | 2592*1944@15Fps,2688*1520/2560*1440@25Fps,2048*1520/2304*1296@25Fps,1080P@30Fps |
Substream: | D1/VGA/ 640*360/480*360/CIF@25fps ,Support CBR/VBR |
Housing | Metal Vandal-proof Housing |
Audio processing | Audio linear input and output,G711U / G711A/ACC coding ,Support two-way intercom , Support alarm sound linkage and the sound can be customized |
Network Interface | RJ45 Interface,10/100M,Adaptive Ethernet interface,2KV Thunder and lightning Protection |
Protocol | Support HIKVISION / Dahua / HTTP/ RTSP /RTMP/ DHCP/ NTP/ ONVIF/P2P/UPNP/GB28181 Protocol and other docking Protocol |
storage | Camera no storage / NVR hard disk storage |
I0 interface | power zoom and auto focus interface Available ,Need to use zoom camera lens and zoom control panel as well as zoom software |
Light board interface | Support passive mode |
IRcut Interface | Integrated IRCUT switching circuit / automatic/ external control, manual control / Timing control Ircut day and night mode |
Business functions | IE 6.0 or above (Device embedded browser Web Serve ) browser browsing Motion detection and OSD customization JPEG snapshot P2P cloud service danale IP filtering ProvideSDK(Windows,Android,Linux)Research and development package |
Camera Lens | 5.0MP 2.8MM / 3.6MM / 4MM / 6MM Lens |
Working Voltage | DC 12V / 2A |
POE | POE Module Inbuild or on line |
IR Lights | 15 pics IR lights |
Working Environment | -30℃ to + 80℃ |
Installation | Surface Wall mounting |
