Effective Megapixels

4K/8MP;5.0MP(2592*1944);4.0MP(2592*1520);3.0MP(2048*1536) ;1080P(1920*1080)

Image Sensor

1/2.8, Sony 335 , 5.0MP IP

Lowest Illumination

Color 0.01 Lux

Resolution

2592(H) * 1944(V)

S/N Ratio

>=50db

Video processing

PAL/NTSC available, support Auto White Balance, 3D noise reduction, Support wide dynamic, Support anti-face overexposure, defogging function, Compression:H.264 / H.265/ H.265+ available, Achieve ultra-low storage, Stream / Fps adjustable

Mainstream:

2592*1944@15Fps,2688*1520/2560*1440@25Fps,2048*1520/2304*1296@25Fps,1080P@30Fps

Substream:

D1/VGA/ 640*360/480*360/CIF@25fps ,Support CBR/VBR

Housing

Metal Vandal-proof Housing

Audio processing

Audio linear input and output,G711U / G711A/ACC coding ,Support two-way intercom , Support alarm sound linkage and the sound can be customized

Network Interface

RJ45 Interface,10/100M,Adaptive Ethernet interface,2KV Thunder and lightning Protection

Protocol

Support HIKVISION / Dahua / HTTP/ RTSP /RTMP/ DHCP/ NTP/ ONVIF/P2P/UPNP/GB28181 Protocol and other docking Protocol

storage

Camera no storage / NVR hard disk storage

I0 interface

power zoom and auto focus interface Available ,Need to use zoom camera lens and zoom control panel as well as zoom software

Light board interface

Support passive mode

IRcut Interface

Integrated IRCUT switching circuit / automatic/ external control, manual control / Timing control Ircut day and night mode

Business functions

IE 6.0 or above (Device embedded browser Web Serve ) browser browsing

Motion detection and OSD customization

JPEG snapshot

P2P cloud service danale

IP filtering

ProvideSDK(Windows,Android,Linux)Research and development package

Camera Lens

5.0MP 2.8MM / 3.6MM / 4MM / 6MM Lens

Working Voltage

DC 12V / 2A

POE

POE Module Inbuild or on line

IR Lights

15 pics IR lights

Working Environment

-30℃ to + 80℃

Installation

Surface Wall mounting
