System structure

dual-core 32-bit DSP(XM550), pure hard compression ,watch dog

Sensor

5MP 1/2.7"SC5335P CMOS sensor

Min. illumination

Color：0.001Lux @(F1.2,AGC ON); 0 Lux with IR; Black/White: 0.0001 Lux @ (F1.2,AGC ON),0 Lux with IR

Video compression

H.265X coding,support dual stream,AVI;0.1M~8Mpbs variable

Image output

Main stream: 2592*1944@12fps; sub-stream: 640*360@12fps

Shutter

1/50(1/60)s to 1/10,000s

Lens

N/A

Day and night

Support IR-CUT

Noise reduction

Support 2D/3D

Wide dynamic

Support digital

Auto iris

N/A

Audio compression

G.711 standard compression,support two-way Bidrectional Talk,support for audio and video synchronization

Audio interface

1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone;

Network interface

1 RJ45 Ethernet interface, 10/100M adaptive

Extension interface

N/A

Singal interface

one IR-CUT interface

PTZ interface

N/A

Alarm I/O

N/A

Wireless interface

1 *Wireless interface,Support WiFi connections

Reset interface

Support

Storage mode

Local TF card storage, up to 128G; cloud storage

Reliability

Comprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing

Intelligence analysis

Support human detection and customizing other intelligent

functions

Other function

Support cloud technology,easy to achieve network penetration,fro in-line and alarm information pushed

ONVIF

Support

Mobile monitoring

Support multiple mobile monitoring（iOS，Android）

Power

DC12V

Dimension
