system

Master chip processor

Dual-core 32-bit DSP (XM650V200), pure hard compression, watchdog

Image sensor

2 2m 1/3.2" SC2331 High performance CMOS sensors

Operating system

Embedded LINUX operating system

Image coding format

Smart H.265X

APP

Super Look (Android and IOS support)

Video

Effective video pixel

2MP

Video processing

H.265AI coding, double code stream,AVI format; Bitstream 0.1M~10Mpbs adjustable; The frame rate is adjustable from 1 to 30 frames
per second

resolution

Main code stream: 1920*1080@12fps; Substream: 800*448@12fps

Minimum illuminance

0.01 LUX/pro series

lens

5x zoom

perspective

90 °

Video flip

Flip up and down/flip side to side

lighting

Light control mode

Starlight full color/intelligent warning/infrared night vision

Number of fill lights

4 infrared +6 white

PTZ

Head control

Rotation Angle level :355°; Vertical :90°

Head flip

Flip up and down/flip side to side

Audio

Coding standard

G.711

pickup

support

horn

support

Record management

Video file size

≈12G/ day

Record Mode

Manual record, motion detection record, scheduled record, alarm record

Video storage

TF Card/Cloud

storage

support TF card（max 128GB) or cloud storage

Remote playback

Support

Image capture

Support

Network

WIFI

2.4G WIFI 802.11b/g/n

Pairing

WiFi Smartlink distribution network addition, AP hotspot addition, QR code scanning. Bluetooth fast networking

Network Protocol

Support TCP/IP, ONVIF, RTSP

extension

Reset key

Support

Human tracking

Support

360degree coordinate positioning

Support

power supply

Power

AC110-230V

power interfac

E27

work environment

Suitable place

outdoor、Home、shop、School、factory；

Installation mode

Wall mounted、hoisting

Working Temperature

-20℃－＋55℃

Working humidity

10%－90%
